  ANCHOR BOLT

  DIN529B

    DIAMETER (D)

 PITCH

   A

 Y

• Dimensions in millimetres

• Y = 5 times the diameter of the anchor

• Thread and overall length to suit customer requirements

• Available in carbon, alloy and stainless steels
